Excerpt:
Hastelloy B-2 (UNS N10665) supplier — ASTM B574/B619/B622. Outstanding resistance to hydrochloric acid at all concentrations. Chemical processing, pharmaceutical. Seamless tubes & bars.
Hangbo Alloy Group offers a diverse range of materials, including round bars, steel plates, strips, seamless pipes, forged products, and wire.
Detailed Introduction to Hastelloy B-2
Hastelloy B-2(UNS N10665) is a nickel-molybdenum alloy renowned for its outstanding resistance to hydrochloric acid at all concentrations and temperatures. It is particularly effective in environments where both reducing and oxidizing conditions are present, making it suitable for a variety of corrosive environments.
The alloy exhibits excellent corrosion resistance against other non-oxidizing acids, such as sulfuric acid and phosphoric acid. Its high molybdenum content contributes to its enhanced performance in these aggressive environments.
Equivalent Grades by Country:
•ASTM: UNS N10665
•DIN: NiMo28
•GB/T: NS3203
International Standards for Hastelloy B-2 Products
The following table outlines the applicable standards for Hastelloy B-2 in various forms:
| Product Form | ASTM Standard |
|---|---|
| Plate,Sheet&Strip | ASTM B333 |
| Round Bar | ASTM B335 |
| Seamless Pipe&Tube | ASTM B622 |
| Welded Pipe&Tube | ASTM B619,ASTM B626 |
ForgingASTM B564,ASTM B462FittingsASTM B366
Chemical Composition of Hastelloy B-2
The chemical composition of Hastelloy B-2 is summarized in the following table:
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | 65.0 - 74.0 |
| Molybdenum (Mo) | 26.0 - 30.0 |
| Iron (Fe) | ≤ 2.0 |
| Chromium (Cr) | ≤ 1.0 |
| Carbon (C) | ≤ 0.02 |
| Silicon (Si) | ≤ 0.10 |
| Manganese (Mn) | ≤ 1.00 |
| Cobalt(Co) | ≤ 1.00 |
| Phosphorus (P) | ≤ 0.040 |
| Sulfur (S) | ≤ 0.030 |
Physical Properties of Hastelloy B-2
Key physical properties of Hastelloy B-2 are outlined in the table below:
| Property | Value |
|---|---|
| Density | 8.9 g/cm³ |
| Melting Point | 1330 - 1380 °C |
Material Characteristics
Hastelloy B-2 is characterized by several key properties:
• Corrosion Resistance: Exceptional resistance to hydrochloric acid and other non-oxidizing acids.
• High Strength: Maintains strength in high-temperature environments.
• Weldability: Can be easily welded using standard techniques, facilitating fabrication.
• Versatility: Effective in both reducing and oxidizing environments.
Applications of Hastelloy B-2
Hastelloy B-2 is utilized across various industries, including:
• Chemical Processing: Equipment such as reactors and heat exchangers that handle corrosive chemicals.
• Oil and Gas: Components exposed to corrosive environments during extraction and processing.
• Pharmaceuticals: Equipment for manufacturing processes involving harsh chemicals.
• Environmental: Systems for waste treatment that require high resistance to aggressive media.
Related Products
- Hastelloy C-22 vs C-276 for Aggressive Chemical Service: Complete Comparison
- Hastelloy B-3 Supplier: Round Bar, Seamless Tube & Plate | Shanghai Hangbo Alloy Group
- Hastelloy X Supplier: Forged Rings, Bars & Sheets | Shanghai Hangbo Alloy Group
- Hastelloy-X
- Hastelloy C-276
- Hastelloy G-30
Mechanical Properties of Hastelloy B-2
| Property | Value |
|---|---|
| Tensile Strength (MPa) | 745 |
| Yield Strength (MPa) | 355 |
| Elongation (%) | 48 |
| Hardness (HRB) | 90-100 |
Frequently Asked Questions about Hastelloy B-2
What is Hastelloy B-2 used for?
Hastelloy B-2 (UNS N10665) is primarily used in hydrochloric acid processing, sulfuric acid plants, vacuum furnaces, chemical reactor vessels handling reducing acids. Its excellent corrosion resistance and high-temperature strength make it ideal for these demanding applications.
What is the temperature range of Hastelloy B-2?
Hastelloy B-2 can operate at temperatures up to 1650F (900C) in reducing environments, depending on the specific application and environmental conditions.
What are the key properties of Hastelloy B-2?
Hastelloy B-2 (UNS N10665) exhibits excellent corrosion resistance, high-temperature strength, good fabricability, and outstanding mechanical properties. It meets standards including ASTM B333, ASME SB333.
What is the difference between Hastelloy B-2 and other nickel alloys?
Hastelloy B-2 has a unique chemical composition (see the composition table above) that gives it specific advantages in certain environments. The combination of elements provides optimal performance for its target applications in hydrochloric acid processing and related industries.
