Excerpt:
Hastelloy G-30 (UNS N06030) supplier — ASTM B582/B619/B622. Excellent resistance to phosphoric acid and fertilizer production environments. Plates, bars, and tubing available.
Hangbo Alloy Group offers a diverse range of materials, including round bars, steel plates, strips, seamless pipes, forged products, and wire. Below is a detailed overview of HASTELLOY G-30:
Detailed Introduction to Hastelloy G-30
Hastelloy G-30 is a nickel-chromium-molybdenum alloy designed for exceptional resistance to pitting and stress corrosion cracking in a variety of corrosive environments. It is particularly effective in handling strong oxidizing media, including nitric acid and various chlorides, making it ideal for chemical processing applications.
This alloy's unique composition allows it to withstand harsh conditions, including high temperatures and the presence of chloride ions, providing enhanced durability compared to many other alloys. Hastelloy G-30 is often used in environments where other materials may fail, due to its superior resistance to both localized and general corrosion.
Equivalent Grades by Country:
• ASTM: UNS N06030
• DIN: NiCrMo-30 W.Nr.2.4603
International Standards for Hastelloy G-30 Products
The following table outlines the applicable standards for Hastelloy G-30 in various forms:
Product Form ASTM Standard
| Plate,Sheet&Strip | ASTM B582 |
| Round Bar | ASTM B472, ASTM B581 |
| Seamless Pipe&Tube | ASTM B622 |
| Welded Pipe&Tube | ASTM B619,STM B626 |
| Forging | ASTM B462 |
| Fittings | ASTM B462 |
Chemical Composition of Hastelloy G-30
The chemical composition of Hastelloy G-30 is summarized in the following table:
| Element | Percentage (%) |
|---|---|
| Nickel (Ni) | Bal |
| Molybdenum (Mo) | 4.0 – 6.0 |
| Iron (Fe) | 13.0-17.0 |
| Chromium (Cr) | 28.0-31.5 |
| Carbon (C) | ≤ 0.03 |
| Silicon (Si) | ≤ 0.80 |
| Manganese (Mn) | ≤ 1.50 |
| Cobalt(Co) | ≤ 5.00 |
| Tungsten(W) | 1.5-4.0 |
| Copper(Cu) | 1.00-2.40 |
| Phosphorus (P) | ≤ 0.040 |
| Sulfur (S) | ≤ 0.020 |
| Nb +Tantalum(Ta) | 0.30-1.50 |
Physical Properties of Hastelloy G-30
Key physical properties of Hastelloy G-30 are outlined in the table below:
| Property | Value |
|---|---|
| Density | 8.22 g/cm³ |
| Melting Point | 1350 - 1390 °C |
Material Characteristics
Hastelloy G-30 is characterized by several key properties:
• Corrosion Resistance: Excellent resistance to pitting, crevice corrosion, and stress corrosion cracking in oxidizing environments.
• High-Temperature Stability: Maintains mechanical integrity and resistance to corrosion at elevated temperatures.
• Weldability: Suitable for welding using common techniques, facilitating ease of fabrication.
• Versatility: Effective in various chemical processes and industries requiring corrosion-resistant materials.
Applications of Hastelloy G-30
Hastelloy G-30 is utilized across various industries, including:
• Chemical Processing: Equipment such as reactors, heat exchangers, and piping systems handling aggressive media.
• Pharmaceuticals: Applications requiring high corrosion resistance in the production of active pharmaceutical ingredients.
• Oil and Gas: Components in upstream and downstream processes, particularly in environments with corrosive substances.
• Environmental: Systems for waste treatment and management, especially where chemical exposure is a concern.
Related Products
- Hastelloy C-22 vs C-276 for Aggressive Chemical Service: Complete Comparison
- Hastelloy B-3 Supplier: Round Bar, Seamless Tube & Plate | Shanghai Hangbo Alloy Group
- Hastelloy X Supplier: Forged Rings, Bars & Sheets | Shanghai Hangbo Alloy Group
- Hastelloy-X
- Hastelloy C-276
- Hastelloy C-22
Mechanical Properties of Hastelloy G-30
| Property | Value |
|---|---|
| Tensile Strength (MPa) | 700 |
| Yield Strength (MPa) | 320 |
| Elongation (%) | 50 |
| Hardness (HRB) | 80-90 |
Frequently Asked Questions about Hastelloy G-30
What is Hastelloy G-30 used for?
Hastelloy G-30 (UNS N06030) is primarily used in phosphoric acid production, fertilizer manufacturing, nuclear fuel reprocessing, sulfuric acid cooling, petrochemical processing. Its excellent corrosion resistance and high-temperature strength make it ideal for these demanding applications.
What is the temperature range of Hastelloy G-30?
Hastelloy G-30 can operate at temperatures up to 1650F (900C) in oxidizing environments, depending on the specific application and environmental conditions.
What are the key properties of Hastelloy G-30?
Hastelloy G-30 (UNS N06030) exhibits excellent corrosion resistance, high-temperature strength, good fabricability, and outstanding mechanical properties. It meets standards including ASTM B582, ASME SB582.
What is the difference between Hastelloy G-30 and other nickel alloys?
Hastelloy G-30 has a unique chemical composition (see the composition table above) that gives it specific advantages in certain environments. The combination of elements provides optimal performance for its target applications in phosphoric acid production and related industries.
