Hangbo Alloy Group offers a wide range of MONEL 400 alloy products, including round bars, plates, strips, seamless tubes, forgings, and wires. Below is a detailed description of the MONEL 400 material.
1. Introduction to MONEL 400
Description: MONEL 400 (UNS N04400) is a nickel-copper alloy known for its excellent corrosion resistance in a wide range of environments, especially in marine and chemical processing. It also offers good mechanical properties from sub-zero to high temperatures.
International Equivalents:
USA: UNS N04400
Europe: DIN 2.4360
China: GB/T 19228
Aerospace: AMS 4544
2. Standards for MONEL 400 Products
Plates: ASTM B127, AMS 4544
Round Bars: ASTM B164, AMS 4675
Seamless Tubes: ASTM B165
Forgings: ASTM B564, DIN 2.4360
3. Chemical Composition of MONEL 400 (in %)
| Element | Content (%) |
|---|---|
| Nickel (Ni) | ≥63.0 |
| Copper (Cu) | 28.0 - 34.0 |
| Iron (Fe) | ≤ 2.50 |
| Manganese (Mn) | ≤ 2.00 |
| Carbon (C) | ≤ 0.30 |
| Silicon (Si) | ≤ 0.50 |
| Sulfur (S) | ≤ 0.024 |
4. Physical Properties of MONEL 400
| Property | Value |
|---|---|
| Density | 8.80 g/cm³ |
| Melting Range | 1300 - 1350 °C |
5. Material Characteristics of MONEL 400
Corrosion Resistance: Highly resistant to seawater, salt, and alkalis.
Temperature Resistance: Retains strength and toughness in sub-zero conditions.
Weldability: Suitable for welding and is often used in applications requiring welded construction.
Non-Magnetic: Exhibits non-magnetic properties, making it suitable for applications in electronic and magnetic fields.
6. Applications of MONEL 400
Marine Engineering: Piping, heat exchangers, and pumps in seawater systems.
Chemical and Hydrocarbon Processing: Tanks, valves, and heat exchangers.
Oil and Gas Industry: High-pressure applications and sour gas environments.
Aerospace: High-temperature and corrosion-resistant components.
Electrical and Electronics: Components in magnetic and corrosive environments.
