| Standard | Fe | C | N | O | H | AI | V |
|---|---|---|---|---|---|---|---|
| ASTM F136 | 0.25 | 0.08 | 0.05 | 0.13 | 0.0120 | 5.5~6.5 | 3.5~4.5 |
| ISO 5823-3 | 0.25 | 0.08 | 0.03 | 0.13 | 0.0125 | 5.5~6.5 | 3.5~4.5 |
Gr23 Ei
| Standard | Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elogation 0.2% offset |
Reduction of Aera (%) |
|---|---|---|---|---|
| ASTM F136 | ≥828 | ≥760 | ≥10 | - |
| ISO 5832-3 | ≥828 | ≥760 | ≥10 | - |
Chemical Composition of Titanium Grade 23 (Ti-6Al-4V ELI) (UNS R56401)
| Element | Content (%) |
|---|---|
| Ti | bal |
| Al | 5.5-6.5 |
| V | 3.5-4.5 |
| Fe | 0.25 max |
| O | 0.13 max |
| C | 0.08 max |
Mechanical Properties of Titanium Grade 23 (Ti-6Al-4V ELI)
| Property | Value |
|---|---|
| Tensile Strength (MPa) | 860 |
| Yield Strength (MPa) | 780 |
| Elongation (%) | 10 |
| Hardness (HRC) | 28-35 |
Applications of Titanium Grade 23 (Ti-6Al-4V ELI)
Titanium Grade 23 (Ti-6Al-4V ELI) (UNS R56401) is widely used in medical implants, surgical instruments, aerospace components, cryogenic applications. The alloy maintains excellent mechanical properties at temperatures up to 750F (400C), making it suitable for demanding high-temperature service environments.
Standards & Specifications: ASTM F136, ASTM B348
Frequently Asked Questions about Titanium Grade 23 (Ti-6Al-4V ELI)
What is Titanium Grade 23 (Ti-6Al-4V ELI) used for?
Titanium Grade 23 (Ti-6Al-4V ELI) (UNS R56401) is primarily used in medical implants, surgical instruments, aerospace components, cryogenic applications. Its excellent corrosion resistance and high-temperature strength make it ideal for these demanding applications.
What is the temperature range of Titanium Grade 23 (Ti-6Al-4V ELI)?
Titanium Grade 23 (Ti-6Al-4V ELI) can operate at temperatures up to 750F (400C), depending on the specific application and environmental conditions.
What are the key properties of Titanium Grade 23 (Ti-6Al-4V ELI)?
Titanium Grade 23 (Ti-6Al-4V ELI) (UNS R56401) exhibits excellent corrosion resistance, high-temperature strength, good fabricability, and outstanding mechanical properties. It meets standards including ASTM F136, ASTM B348.
What is the difference between Titanium Grade 23 (Ti-6Al-4V ELI) and other nickel alloys?
Titanium Grade 23 (Ti-6Al-4V ELI) has a unique chemical composition (see the composition table above) that gives it specific advantages in certain environments. The combination of elements provides optimal performance for its target applications in medical implants and related industries.
